How to Specify Knitted Bag Yarn: A Buyer's Spec Sheet for Dtex, Gauge and GSM

What a Yarn Spec Has to Contain Before Sampling Starts

A knitted bag yarn specification is complete when it answers four questions in a fixed order: fibre family, count and filament, gauge and loop length, and the mechanical floor the finished panel has to clear. Anything less and the first sample is a guess. Most disappointing samples are not caused by bad knitting; they are caused by a spec that named a colour and a shape but never named a count, a tenacity or a test method, so the technician had to choose those numbers alone. Write the four blocks down and the first sample usually lands close enough to measure against a target rather than reject outright.

The order matters because each decision constrains the next one. Fibre family sets the tenacity ceiling and the dye route. Count and filament set which gauges the yarn will actually run on, because a 600D yarn will not form a clean loop at E14. Gauge and loop length then set the fabric mass in g/m², which sets cost per bag and the stiffness of the finished panel. Performance is the last line, not the first: you cannot ask for 40,000 Martindale cycles from a yarn and gauge combination that physically cannot deliver it, and a spec that asks for impossible numbers simply moves the failure to the inspection report.

A useful test of whether a spec is ready: hand it to a technician who has never spoken to you and ask whether they can load a machine without asking a question. If the sheet says recycled nylon, E12, 420 g/m², 25,000 cycles, shrinkage within 3%, colour fastness 4, packed flat, FOB Xiamen, the answer is yes. If it says soft hand feel and strong, the answer is no, and the sampling clock has not really started.

Fibre Family: PA6, PET and the Recycled Routes

PA6 (nylon 6) is the default for knitted bags that will be loaded hard, because filament PA6 delivers roughly 4.5 cN/dtex tenacity with around 28% elongation at break, which absorbs shock at the handle roots. PET (polyester) sits nearer 22% elongation, holds shape better under humidity, and dyes with disperse dyes at high temperature. The two behave differently at the loop: nylon recovers from stretch, polyester resists it. Choosing between them is a decision about what the bag will meet in use, not about which name sounds better on a hangtag.

Recycled routes now cover both families. Recycled PA6 typically comes from post-industrial waste such as fishing net and carpet face fibre, and mechanical recycling costs you a little tenacity: plan on about 4.0 cN/dtex rather than 4.5 cN/dtex, which is a real but manageable drop if you compensate with count or stitch density. Recycled PET from bottle flake is the more mature route and is widely available at consistent quality. Either route needs documentation at yarn level, and the document that matters for resale claims is the GRS transaction certificate issued against the specific yarn lot, not a generic mill statement.

• PA6 filament: tenacity around 4.5 cN/dtex, elongation about 28%, moisture regain near 4.5%, best shock recovery at handle roots.
• PET filament: tenacity around 4.2 cN/dtex, elongation about 22%, moisture regain near 0.4%, better dimensional stability in humid transit.
• Recycled PA6: plan for about 4.0 cN/dtex and verify the recycled content claim with a GRS transaction certificate tied to the lot.
• Recycled PET: the most mature recycled route, usually with lower lot-to-lot variation than recycled polyamide.
• Blends: a PA6 core with PET sheath is used when a buyer wants nylon toughness with polyester dye economics.

Count and Filament: Reading 150D, 300D and 600D

The count in denier tells you mass per 9,000 m of yarn and the filament figure after the slash tells you how many individual filaments make up that yarn, so 300D/96f is a 300 denier yarn built from 96 filaments. Two yarns with the same denier and different filament counts do not behave the same: more filaments means a softer hand and better cover, fewer filaments means higher abrasion resistance and a crisper surface. For bag bodies the working range is roughly 150D for light liners, 300D for general-purpose bodies, and 600D for base panels and load-bearing zones.

Write the count as denier plus filament, never as denier alone, and add the twist level in turns per metre because twist changes abrasion and pilling behaviour at the same count. A 600 TPM twist on a 300D yarn gives a tighter, harder surface that resists scuffing on a base panel; drop to 350 TPM and the same yarn reads softer and picks up abrasion marks sooner. Filament yarns for knitting are usually flat or lightly textured; heavily textured yarns add bulk and softness but lose around 15% of the tenacity of the flat equivalent, which matters if your spec also carries a tensile floor.

Gauge, Loop Length and the Stitch That Carries Load

Gauge is the number of needles per inch on the machine bed, written as E7, E12 or E14, and loop length is the length of yarn fed into a single loop, typically 4.2 mm at E12 and around 6.8 mm at E7. Fabric mass in g/m² is the product of yarn count, gauge and loop length, not an independent choice, which is why a buyer cannot ask for 300D at E12 and 280 g/m² in the same breath. Stitch density follows from the same three numbers: an E12 panel at 4.2 mm loop length typically lands near 5.6 courses per cm and 4.8 wales per cm.

Stitch structure is the fourth lever and it is where most of the engineering value sits. A single jersey panel is the lowest-cost structure and rolls at the edges, so it needs a border treatment. Half-gauge rib and interlock add stability and thickness without changing yarn. Tuck and float structures let a technician place a denser, more abrasion-resistant zone in the base of a bag while the same panel stays lighter at the sides, all in one knitting cycle with no cutting and no sewing. That zoned approach is the main reason to knit a bag rather than cut and sew one, and it should be specified as a drawing with zones marked, not as a written note.

Machine gauge

E7, E12 or E14 needles per inch

Loop length at E12

about 4.2 mm

Loop length at E7

about 6.8 mm

Courses per cm (E12)

about 5.6

Wales per cm (E12)

about 4.8

Twist level

350 to 600 turns per metre

Zoned structures

tuck and float for base and handle roots

Tenacity, Elongation and Abrasion: Three Numbers That Decide Returns

Three mechanical numbers decide whether a knitted bag programme survives its first season: tensile strength by ISO 13934-1, abrasion resistance by ISO 12947-2 (Martindale), and tear strength by ISO 13937-2. Write the number and the standard together, because 450 N means nothing without the method. A reasonable floor for a 300D E12 body panel is around 450 N tensile in the strip test, 25,000 Martindale cycles at 12 kPa before a visible break, and about 35 N tear resistance. Base panels and handle roots should carry a higher abrasion floor because that is where returns actually originate.

Elongation and shrinkage belong in the same block. Knitted structures move under load, so a bag that stretches 6% at the handle under an 8 kg load and does not recover will look tired by the third week of retail handling. Set a dimensional stability target of 3% maximum after washing and a handle elongation limit rather than leaving them to chance. Because these are measurable, they belong in the inspection plan, which is where AQL 2.5 under ISO 2859-1 comes in: the sampling plan tells you how many units to pull and what defect count to accept, but the spec has to tell the inspector what counts as a defect in the first place.

Colour, Lot and Fastness Specification

Colour has to be specified as a numbered reference plus a tolerance, not as a name. A workable line reads: match Pantone 19-4053, instrument tolerance dE 1.0 under D65, grey scale ISO 105-A02 grade 4-5. Without the tolerance, colour disputes become opinion. Add a lot rule as well: for a programme running across more than one production month, require that all yarn comes from a single dye lot, or accept a defined dE window between lots and record it, because knitted panels from two lots placed side by side in one bag will show a seam-like line that reads as a defect even though no test fails.

Fastness belongs next to colour because the two are decided together. Wash fastness by ISO 105-C06, light fastness by ISO 105-B02, and rubbing by AATCC 8 are the three that matter for bags. A dark navy on recycled PA6 can struggle to hit grade 4 wet crocking, and the fix is a reduction-clear after dyeing rather than a different dyestuff class, so it is worth writing the requirement into the spec early enough that the dye route can be planned. Where a bag carries a light panel next to a dark one, add a colour transfer check to the same clause.

• Name the reference: a numbered Pantone or a physical approved swatch, never a colour name alone.
• Set the tolerance: instrument dE, illuminant, and whether the tolerance applies to the panel or to the yarn.
• Fix the lot rule: one dye lot per programme, or a declared inter-lot dE window recorded before bulk.
• Set the fastness floor: ISO 105-C06 grade 4, ISO 105-B02 grade 4, AATCC 8 grade 4-5 dry.

Compliance Lines to Write Into the Spec

Compliance costs least when it is written into the yarn spec rather than added after the first bulk run fails a retailer check. The clauses worth writing are: OEKO-TEX STANDARD 100 for the finished fabric, REACH Annex XVII restricted substance conformance for the EU, California Prop 65 for the US, CPSIA lead and phthalate limits for children's items, and GRS transaction certificates for any recycled content claim. Each one has a document that a buyer should be able to file, and the spec should name the document and the validity window rather than the logo.

What the Spec Does to Cost and Lead Time

Every line in a yarn spec moves cost, and the three heaviest levers are count, recycled content and abrasion floor. Going from 300D to 450D raises yarn consumption per bag roughly in proportion to the denier increase, which shows up directly in fabric mass and in the landed cost per piece. Recycled PA6 typically carries a premium over virgin PA6 per kilogram, and the premium is largest on small lots because the recycled route has minimum dye batch economics. Raising the Martindale floor from 25,000 to 40,000 cycles usually means either a heavier yarn or a denser stitch, and both cost mass rather than money per kilogram.

Lead time is affected by a different set of lines. Sampling is 7 working days from a locked spec, but that clock starts when the yarn is available, and a custom colour or a recycled lot that has to be spun pushes the yarn lead time ahead of the knitting. Bulk runs 30 days from approved sample, and the two things that break a 30-day plan are a colour approval that drifts and a yarn lot that has to be re-dyed. Programmes start at 100 pcs per style and colourway, quoted FOB Xiamen with CIF and DDP available; a reference landed figure for a mid-weight knitted tote sits around USD 4.80 at that quantity, and the yarn spec is the single largest variable inside it.

A Worked Yarn Spec You Can Copy

The fastest way to write a first spec is to copy a complete one and edit the numbers. The sheet below is a realistic mid-weight knitted tote programme: recycled PA6 at 300D/96f, knitted at E12 to a finished 420 g/m², with a zoned denser base, tested against the four methods named above. It is deliberately unambitious in the right places: the abrasion floor is set at 25,000 cycles for the body and raised only in the base, and the colour tolerance is dE 1.0 on the main colourway and dE 1.5 on secondary ones, which keeps the dye route economically workable at 100 pcs.

Yarn

300D/96f recycled PA6, 480 TPM, GRS transaction certificate

Gauge and loop length

E12, 4.2 mm, zoned tuck structure in the base

Finished fabric

420 g/m², tolerance ±5%

Tensile

450 N minimum, ISO 13934-1, both directions

Abrasion

25,000 cycles body, 40,000 cycles base, ISO 12947-2 at 12 kPa

Tear

35 N minimum, ISO 13937-2

Colour

Pantone reference, dE 1.0 D65, ISO 105-A02 grade 4-5

Fastness

ISO 105-C06 grade 4, ISO 105-B02 grade 4, AATCC 8 grade 4-5 dry

Shrinkage

3% maximum after wash, measured on a 30 cm marking

Programme

100 pcs per style and colourway, 7 working days sampling, 30 days bulk

Inspection and terms

AQL 2.5 under ISO 2859-1, FOB Xiamen, CIF and DDP available

Checklist Before You Release the Spec to Bulk

A spec is released to bulk when the sample has been tested against it, not when it looks right. The sequence below is what separates a 30-day bulk run that ships on plan from one that spends three weeks in re-dye. Run it in order: approve the hand and the structure first, then the measurements, then the test reports, and only then release colour, because colour approvals are the ones most often reversed after the fact and a reversed colour approval after bulk has started costs the full yarn lot.

1. Confirm the yarn identity on the cone label matches the spec: denier, filament count, twist, recycled claim.
2. Measure the sample fabric mass and stitch density against the g/m² and the courses per cm in the spec.
3. Have the panel tested for tensile, abrasion and tear before approving the structure.
4. Check dimensional stability after wash, and re-measure the panel against the marking.
5. Approve colour under the illuminant named in the spec, and record the dye lot number.
6. Confirm the compliance file: OEKO-TEX, REACH, Prop 65, GRS certificate for the delivered lot.
7. Release bulk only after the test reports and the colour approval are both filed against the same lot number.
